Anti-Light Projection Film | Medium-Long Throw | NRXXXS Series
The NRXXXS Series is a premium anti-light projection base film engineered for front projection applications with medium to long throw ratio (0.6–1.6). It features a multi-layer optical microstructure and embedded nano particles, delivering superior ambient light rejection, excellent color fidelity, and uniform brightness.
With an ambient light rejection rate of ≥85% and a wide viewing angle of up to 155° in dark environments, it significantly improves image contrast and sharpness even under indoor lighting. Made from high-grade polymer resin, it is durable, easy to process, and ideal for high-performance projection screen manufacturing.
OEM and custom cutting available.
Applications:
Projection screen manufacturing, home theater, commercial display, education, conference systems, exhibition displays.
Storage Conditions:
Temperature: -10°C to 40°C
Humidity: 30%–70% RH
Shelf Life: 12 months
Do not bend or fold. Handle with gloves to avoid fingerprint and scratches.
Product successfully added to the Quote List
- Extensive Manufacturing Experience
- Strict Quality Control
- Flexible Customization Capability
- Competitive Cost & On-Time Delivery
- Dedicated Professional Service
Product Specifications Table
| Model | NRXXXS-80 / NRXXXS-100 / NRXXXS-118 |
|---|---|
| Projection Type | Medium to long throw (0.6–1.6) |
| Film Type | Anti-light optical base film |
| Peak Gain | ≤1.55 |
| Viewing Angle (Bright Room ≤250lx) | ≥55° (half-gain angle) |
| Viewing Angle (Dark Room ≤10lx) | ≥155° (half-gain angle) |
| Ambient Light Rejection | ≥85% |
| Brightness Uniformity | ≥88% |
| Contrast Ratio (Bright Room) | 80:1 |
| Material | Polymer resin |
| Thickness Tolerance | ±0.02 mm (@25°C, 50%RH) |
| Diagonal Tolerance | ±2.5 mm (@25°C, 50%RH) |
Available Sizes (NR188S Series)
| Model | Width (mm) | Length (mm) | Thickness (mm) |
|---|---|---|---|
| NR188S-80 | 1792 | 1017 | 0.21 |
| NR188S-100 | 2225 | 1256 | 0.21 |
| NR188S-118 | 2640 | 1480 | 0.21 |
Available Sizes (NR250S Series)
| Model | Width (mm) | Length (mm) | Thickness (mm) |
|---|---|---|---|
| NR250S-80 | 1792 | 1017 | 0.28 |
| NR250S-100 | 2225 | 1256 | 0.28 |
| NR250S-118 | 2640 | 1480 | 0.28 |
